Pump Drive: CO2 gas, Nitrogen or compressed dry filtered air
Materials of Construction: (wetted parts:) Polypropylene, Santoprene®, EPDM, AISI 303 & 304 Stainless Steel
Displacement US Gallons (litres): 3.2 oz (91ml) per cycle
Operating Pressure:20 - 90 PSI; 1.4 - 6.2 bar max
Operating temperature: 34°F to 120°F; 1.1°C to 49°C
Maximum Liquid Inlet Pressure: 30 psi; 2.1 bar max
Flow Rate US gallons (litres): 5 GPM (18.9 LPM) - open flow
Dimensions (H x W x D): 5.27 x 3.21 x 4.58 (inches) 133.8 x 81.5 x 116.3 (mm)
Warranty Period: 1 year
Approvals: CE, SK, NSF Standard 18
Weight: 0.56 (kg) 1.24 (lb)
Product Inlet Fitting: 1/2" (9.52mm) Barbed Straight Plastic(Polypropylene)
Product Outlet Fitting: 1/2" (9.52mm) Barbed Straight Plastic (Polypropylene)
Gas/Air Inlet Fitting: 1/4" (6.35mm) CO2 Shutoff Brass
